Optical Fiber Filling Gel
Product Introduction
Optical fiber filling gel is a white translucent paste, which consists of base oil, inorganic filler, thickener, regulator, antioxidant, etc., heated in a certain proportion and homogenized in a reaction kettle , and then colloid grinding, cooling and degassing
For outdoor optical cable, in order to prevent water and moisture from reducing the strength of the optical fiber and increasing the transmission loss which affects the communication quality, it is necessary to fill the loose tube of the optical cable with water-blocking materials such as optical fiber filling gel to achieve the effect of sealing and waterproofing, anti-stress buffering, and protecting the optical fiber. The quality of the optical fiber filling gel directly affects the stability of the optical fiber transmission performance and the life of optical cable.
We can provide various types of optical fiber filling gel, mainly including ordinary optical fiber filling gel (suitable for filling around optical fibers in ordinary loose tube), filling gel for optical fiber ribbons (suitable for filling around optical fiber ribbons), hydrogen-absorbing optical fiber filling gel (suitable for filling around the optical fiber in metal tube) etc,.
The optical fiber filling gel provided by our company has good chemical stability, temperature stability, water-repellent, thixotropy, minimal hydrogen evolution, less bubbles, good compatibility with optical fibers and loose tubes, and is non-toxic and harmless to humans.
Application
Mainly used for filling in plastic loose tubes and metal loose tubes of outdoor loose-tube optical cable, OPGW optical cable and other products.
OW-210 type optical fiber filling gel for ordinary loose tube
|
No. |
Item |
Unit |
Parameters |
|
1 |
Appearance |
/ |
Homogeneous,no impurities |
|
2 |
Dropping point |
℃ |
≥200 |
|
3 |
Density (20℃) |
g／cm3 |
0.83±0.03 |
|
4 |
Cone penetration
25℃ －40℃ |
1／10mm |
435±30 ≥230 |
|
5 |
Color stability（130℃,120h） |
/ |
≤2.5 |
|
6 |
Oxidation induction time（10℃／min,190℃） |
min |
≥30 |
|
7 |
Flashing point |
℃ |
＞200 |
|
8 |
Hydrogen evolution（80℃,24h） |
μl／g |
≤0.03 |
|
9 |
Oil perspiring（80℃,24h） |
% |
≤0.5 |
|
10 |
Evaporation capacity（80℃,24h） |
% |
≤0.5 |
|
11 |
Water resistance（23℃,7×24h） |
/ |
Non-disassembly |
|
12 |
Acid value |
mgK0H／g |
≤0.3 |
|
13 |
Water content |
% |
≤0.01 |
|
14 |
Viscosity（25℃,D=50s-1） |
mPa.s |
4600±1000 |
|
15 |
Compatibility：
A、with optical fiber, optical fiber ribbons coating material （85℃±1℃,30×24h） B、with loose tubes material （85℃±1℃,30×24h） variation in tensile strength Breaking elongation mass variation |
% % % |
No fading, migration, delamination, cracking Maximum release force:1.0N～8.9N Average value:1.0N～5.0N No delamination, cracking ≤25 ≤30 ≤3 |
|
16 |
Corrosive（80℃,14×24h）
with copper, aluminum, steel |
/ |
No corrosion points |
| Tips: suitable for filling in ordinary loose tube. | |||
OW-220 type micro optical fiber filling gel
|
No. |
Item |
Unit |
Parameters |
|
1 |
Appearance |
/ |
Homogeneous,no impurities |
|
2 |
Dropping point |
℃ |
≥150 |
|
3 |
Density (20℃) |
g／cm3 |
0.84±0.03 |
|
4 |
Cone penetration
25℃ －40℃ |
1／10mm |
600±30 ≥230 |
|
5 |
Color stability（130℃,120h） |
/ |
≤2.5 |
|
6 |
Oxidation induction time（10℃／min,190℃） |
min |
≥30 |
|
7 |
Flashing point |
℃ |
＞200 |
|
8 |
Hydrogen evolution（80℃,24h） |
μl／g |
≤0.03 |
|
9 |
Oil perspiring（80℃,24h） |
% |
≤0.5 |
|
10 |
Evaporation capacity（80℃,24h） |
% |
≤0.5 |
|
11 |
Water resistance（23℃,7×24h） |
/ |
Non-disassembly |
|
12 |
Acid value |
mgK0H／g |
≤0.3 |
|
13 |
Water content |
% |
≤0.01 |
|
14 |
Viscosity（25℃,D=50s-1） |
mPa.s |
2000±1000 |
|
15 |
Compatibility：
A、with optical fiber, optical fiber ribbons coating material （85℃±1℃,30×24h） B、with loose tubes material （85℃±1℃,30×24h） variation in tensile strength Breaking elongation mass variation |
% % % |
No fading, migration, delamination, cracking Maximum release force:1.0N～8.9N Average value:1.0N～5.0N No delamination, cracking ≤25 ≤30 ≤3 |
|
16 |
Corrosive（80℃,14×24h） with copper, aluminum, steel |
/ |
No corrosion points |
| Tips: suitable for filling in micro cable or small diameter loose tube fiber optic cable. | |||
OW-230 type ribbon optical fiber filling gel
|
No. |
Item |
Unit |
Parameters |
|
1 |
Appearance |
/ |
Homogeneous,no impurities |
|
2 |
Dropping point |
℃ |
≥200 |
|
3 |
Density (20℃) |
g／cm3 |
0.84±0.03 |
|
4 |
Cone penetration
25℃ －40℃ |
1／10mm |
400±30 ≥220 |
|
5 |
Color stability（130℃,120h） |
/ |
≤2.5 |
|
6 |
Oxidation induction time（10℃／min,190℃） |
min |
≥30 |
|
7 |
Flashing point |
℃ |
＞200 |
|
8 |
Hydrogen evolution（80℃,24h） |
μl／g |
≤0.03 |
|
9 |
Oil perspiring（80℃,24h） |
% |
≤0.5 |
|
10 |
Evaporation capacity（80℃,24h） |
% |
≤0.5 |
|
11 |
Water resistance（23℃,7×24h） |
/ |
Non-disassembly |
|
12 |
Acid value |
mgK0H／g |
≤0.3 |
|
13 |
Water content |
% |
≤0.01 |
|
14 |
Viscosity（25℃,D=50s-1） |
mPa.s |
8000±2000 |
|
15 |
Compatibility：
A、with optical fiber, optical fiber ribbons coating material （85℃±1℃,30×24h） B、with loose tubes material （85℃±1℃,30×24h） variation in tensile strength Breaking elongation mass variation |
% % % |
No fading, migration, delamination, cracking Maximum release force:1.0N～8.9N Average value:1.0N～5.0N No delamination, cracking ≤25 ≤30 ≤3 |
|
16 |
Corrosive（80℃,14×24h） with copper, aluminum, steel |
/ |
No corrosion points |
| Tips: suitable for filling in loose tubes containing fiber optic ribbons | |||
OW-240 type metal tube optical fiber filling gel
|
No. |
Item |
Unit |
Parameters |
|
1 |
Appearance |
/ |
Homogeneous,no impurities |
|
2 |
Dropping point |
℃ |
≥200 |
|
3 |
Density (20℃) |
g／cm3 |
0.86±0.02 |
|
4 |
Cone penetration
25℃ －40℃ |
1／10mm |
430±30 ≥230 |
|
5 |
Color stability（130℃,120h） |
/ |
≤2.5 |
|
6 |
Oxidation induction time（10℃／min,190℃） |
min |
≥30 |
|
7 |
Flashing point |
℃ |
＞200 |
|
8 |
Hydrogen evolution（80℃,24h） |
μl／g |
≤0.03 |
|
9 |
Oil perspiring（80℃,24h） |
% |
≤0.5 |
|
10 |
Evaporation capacity（80℃,24h） |
% |
≤0.5 |
|
11 |
Water resistance（23℃,7×24h） |
Non-disassembly |
|
|
12 |
Acid value |
mgK0H／g |
≤0.3 |
|
13 |
Water content |
% |
≤0.01 |
|
14 |
Viscosity（25℃,D=50s-1） |
mPa.s |
5500±1000 |
|
15 |
Compatibility：
A、with optical fiber, optical fiber ribbons coating material （85℃±1℃,30×24h） B、with loose tubes material （85℃±1℃,30×24h） variation in tensile strength Breaking elongation mass variation |
% % % |
No fading, migration, delamination, cracking Maximum release force:1.0N～8.9N Average value:1.0N～5.0N No delamination, cracking ≤25 ≤30 ≤3 |
|
16 |
Corrosive（80℃,14×24h） with copper, aluminum, steel |
/ |
No corrosion points |
| Tips: suitable for filling in metal loose tubes. | |||
Packaging
The product is packaged in dry, clean and rust-free iron barrels, with a net weight of 170kg per barrel.
Storage
1) The product should be kept in a clean, hygienic, dry and ventilated storehouse.
2) The product should be kept away from heat sources, should not be stacked together with flammable products and should not be close to fire sources.
3) The product should avoid direct sunlight and rain.
4) The product should be packed completely to avoid moisture and pollution.
5) The storage period of the product at ordinary temperature is 3 years from the date of production.
|
No. |
Item |
Unit |
Index |
|
1 |
Appearance |
/ |
Homogeneous,no impurities |
|
2 |
Dropping point |
℃ |
≥150 |
|
3 |
Density (20℃) |
g／cm3 |
0.84±0.03 |
|
4 |
Cone penetration25℃－40℃ |
1／10mm |
600±30 ≥230 |
|
5 |
Color stability（130℃,120h） |
/ |
≤2.5 |
|
6 |
Oxidation induction time（10℃／min,190℃） |
min |
≥30 |
|
7 |
Flashing point |
℃ |
＞200 |
|
8 |
Hydrogen evolution（80℃,24h） |
μl／g |
≤0.03 |
|
9 |
Oil perspiring（80℃,24h） |
% |
≤0.5 |
|
10 |
Evaporation capacity（80℃,24h） |
% |
≤0.5 |
|
11 |
Water resistance（23℃,7×24h） |
/ |
Non-disassembly |
|
12 |
Acid value |
mgK0H／g |
≤0.3 |
|
13 |
Water content |
% |
≤0.01 |
|
14 |
Viscosity（25℃,D=50s-1） |
mPa.s |
2000±1000 |
|
15 |
Compatibility： A、with optical fiber,optical fiber ribbons coatingmaterial（85℃±1℃,30×24h） B、with loose tubes material （85℃±1℃,30×24h） variation in tensile strength Breaking elongation mass variation |
% % % |
No fading, migration, delamination, cracking Maximum release force:1.0N～8.9N Average value:1.0N～5.0N No delamination, cracking ≤25 ≤30 ≤3 |
|
16 |
Corrosive（80℃,14×24h）with copper, aluminum, steel |
/ |
No corrosion points |
| Tips: suitable for filling in micro cable or small diameter loose tube fiber optic cable. | |||
