Copper Tape for MV&LV Cable Shielding


  • Payment Terms T/T, L/C, D/P, etc.
  • Delivery Time 20 days
  • Place of Origin China
  • Port of Loading Shanghai, China
  • Shipping By sea
  • HS Code 7409111000
  • Packaging Carton or wooden box, 50kg/pack or according to client's requirement
  • Product Detail

    FAQ

    Product Introduction

    The copper tape is one of the very important raw materials used in cables with high electrical conductivity, mechanical strength and good processing performance which is suitable for wrapping, longitudinal wrapping, argon arc welding, and embossing. It can be used as a metal shielding layer of medium and low-voltage power cables, passing capacitive current during normal operation, acting as a channel for short-circuit current when the system is short-circuited, also shielding the electric field; it can be used as a shielding layer of control cables, communication cables, etc, resisting electromagnetic interference and preventing electromagnetic signal leakage; it can also be used as the outer conductor of the coaxial cables, acting as a channel for current transmission, and shielding electromagnetic.
    Compared with aluminum tape /aluminum alloy tape, the copper tape has higher conductivity and shielding performance, and is an ideal shielding material used in cables.

    The copper tape we provided has the following characteristics:
    1) The surface is smooth and clean, without defects such as curling, cracks, peeling, burrs, etc.
    2) It has excellent mechanical and electrical properties which is suitable for processing with wrapping, longitudinal wrapping, argon arc welding and embossing.

    Application

    The copper tape is suitable for metal shielding layer and outer conductor of medium and low voltage power cables, control cables, communication cables, and coaxial cables.

    Technical Parameters

    Nominal thickness

    (mm)

    Grade

    Code

    Status

    Tensile strength

    (MPa)

    Breaking elongation

    (A11.3/%)

    Volume resistivity(Ω·mm2/m)

    0.05

    0.08

    0.10

    0.12

    TU1

    T10150

    O60

    200~260

    ≥35

    ≤0.017241

    O80

    220~275

    ≥32

    ≤0.017415

    O81

    235~290

    ≥30

    ≤0.017593

    TU2

    T10180

    O60

    200~260

    ≥35

    ≤0.017415

    O80

    220~275

    ≥32

    ≤0.017593

    O81

    235~290

    ≥30

    ≤0.017774

    TU3

    C10200

    O60

    200~260

    ≥35

    ≤0.017241

    O80

    220~275

    ≥32

    ≤0.017415

    O81

    235~290

    ≥30

    ≤0.017593

    TUP0.003

    C10300

    O60

    200~260

    ≥35

    ≤0.017593

    O80

    220~275

    ≥32

    ≤0.017774

    O81

    235~290

    ≥30

    ≤0.017959

    T2

    C12000

    O60

    220~270

    ≥30

    ≤0.017593

    O80

    230~285

    ≥28

    ≤0.017774

    O81

    245~300

    ≥25

    ≤0.017959

    Remarks: The length and width of the copper tape can be provided according to customers’ requirements; In addition to the specifications in the sheet, copper tapes with other grades, status and thicknesses can also be provided according to customers’ needs.

    Storage Method

    1) The product should be stored in a clean, hygienic, ventilated and dry warehouse;
    2) The product should not be stored together with active chemical products such as acid and alkali and items with high humidity;
    3) The room temperature for product storage should be (16~35)℃ and the relative humidity should be below 70%;
    4) Do not open the package immediately when suddenly change the storage area from a low temperature to a high temperature. It should be stored in a dry place for a certain period, open the package after the product temperature rises to prevent oxidation of the product;
    5) The product should be protected from heavy pressure, beating and other mechanical damage during storage and transportation.
